3 Step Steel Stringer DIY Stair Riser, Screws included

Model NO.: QT-FT02
Ref.NO.: 151700-0010
Brief Description: 3 Step Steel Stringer Stair riser. (screws included)
Designed to build a sturdy and lasting staircase, it can be used in residential/commercial applications.
Position: For outdoor stairs use
Application: For residential/commercial
Main Material: Steel
Surface Finish: Matt Black Powder-coated Black
Size: Lengh*Height 794*696mm

Details

The 3-Step Steel Stringer DIY Stair Riser from TENGYU is the perfect solution for your home improvement needs. This high-quality stair riser is designed to make your DIY stair installation project a breeze. The kit includes a durable steel stringer and all the necessary screws for a secure and stable installation.

One of the standout features of this DIY Stair Riser is its 3-step design. With three pre-cut steps, this stringer is ideal for creating a small staircase or replacing an existing one. Whether you’re looking to add stairs to your deck, porch, or any other area of your home, this versatile product has you covered.

Crafted from premium steel, the stringer offers exceptional strength and durability. It can withstand heavy foot traffic and the elements, ensuring your stairs remain sturdy and reliable for years to come. The steel construction also provides a modern and sleek appearance, enhancing the overall look of your space.

Installation is a breeze with the included screws. Simply follow the provided instructions to attach the stringer to your desired location. The pre-drilled holes in the stringer align perfectly with the screws, making the process straightforward and hassle-free. No special tools or expertise are required, making this DIY Stair Riser accessible to homeowners of all skill levels.

Safety is a top priority with this product. The steel stringer offers excellent stability, ensuring each step is secure and level. The textured surface of the steps provides added traction, reducing the risk of slips and falls. With this DIY Stair Riser, you can have peace of mind knowing that your stairs are safe and reliable.

Installation Manual

Technical drawing of a 2 Step Steel Stringer Outdoor Stair Riser with detailed measurements and screw assembly guide, indicating parts and dimensions.

STAIR RISER – INSTRUCTIONS

  1. Bolt stringers to deck (for concrete base) with provided Hex Sleeve Anchor Bolts, not more than 3′ apart (treads may extend over side of each riser by 6″). First tread should be 9″ down from deck surface (7-1/2″ once treads are installed).
  2. Bolt bottom of stringers to landing or concrete pad with provided Hex Sleeve Anchor Bolts – ensure stringers are parallel.
  3. Starting half way up, install treads using provided Self-Tapping Screws (ST6.3).
  4. Please remember not to over-tighten.

DO NOT OVER TIGHTEN




Product Package

Packing Method This product can be installed single, two, three, with a cable tie to fix the bracket; Wrap pearl cotton and put it in a carton. The screws are put into the box and then put into the carton. Both ends of the bracket are protected by paper corner guards.Finally, the carton outer blister packing
Sales Unit Packing Type Carton
Sales Unit Packing Size 1110*470*55mm
QTY/Pallet 30 Sets/PLT
